Product Details
Place of Origin: China
Brand Name: LKS or customized
Certification: CE, FCC
Model Number: LKS8501A
Payment & Shipping Terms
Minimum Order Quantity: 5 Units
Packaging Details: Film wrap, foam and wooden box
Delivery Time: 4-6 weeks upon payment
Payment Terms: T/T in advance, Western Union, L/C
Supply Ability: 1000 units per month
12 Inch Screen: |
Capacitive Touchable |
22 Inch Screen: |
LED / LCD TFT Monitor |
Type: |
Free Standing Dual Screen Kiosk |
Cheque: |
Scan And Storage |
Billnote: |
Validate And Accept |
Receipt Printer: |
80 Mm Width |
12 Inch Screen: |
Capacitive Touchable |
22 Inch Screen: |
LED / LCD TFT Monitor |
Type: |
Free Standing Dual Screen Kiosk |
Cheque: |
Scan And Storage |
Billnote: |
Validate And Accept |
Receipt Printer: |
80 Mm Width |
Sleek design, digitally guest-friendly, part of the PMS
Today’s travelers' preferences are dominated by mixing the best of traditional and digital experiences. Give them what they expect and make their first, or last, impressions last.
► Improves guest experience
► Extremely guest friendly
► Not just integrated, part of your PMS
► Beautifully crafted hardware
Traditional hotels:
The self-service option on a hotel kiosk is an alternative to traditional front desk service
full-service hotel kiosk check-in illustration
For full-service properties, LEAN Kiosk can let hotels automate the check-in formalities so that staff has more time for real human communication with guests. It can also give guests a way to skip the reception altogether.
Self-service hotels:
LEAN Kiosk offers a completely automated replacement of the standard check-in/out service
illustration of kiosk check-in in self-service hotels
For self-service properties, the LEAN Kiosk will enable a practically humanless reception. It will guide guests through a secure, yet fast check-in - from collecting the required advance payment through filling in the registration cards and issuing room keys.
| Image | Component | Specification |
|
PC | ♦CPU: Intel dual-core I3; ♦RAM: 4G; ♦SSD: 120G; ♦Graphics: Integrated Intel HD graphics, 4K support (features depends on processor); ♦Video-outputs: 1x HDMI, 2x DisplayPort ; ♦Other connectors: SD card reader, 2x audio (line out, mic) 4x USB 3.0, 2x USB 2.0, 1x eSATA/USB 2x Intel Gigabit LAN (RJ45), supports WOL 2x COM port (RS232 + RS232/RS422/RS485) 1x PS/2-Combo (supports mouse/keyboard) Connector for the external power button “Always on” Jumper, DC-input 12V+19V ♦PC power supply: External 90W fanless power adapter ♦Operation system: Compatible with Windows 7 / 8.1 /Win10 ♦Customer can install the O.S with license locally |
|
Card dispenser | ♦Power Supply: DC24V± 5% ♦Interface: TTL/RS232 ♦Card Tank Volume 175pcs @ 0.8mm; 130pcs for concavo-convex character number card; 350pcs @ 0.4mm thickness cards ♦Card size: 54 +/- 1.5mm cards relief; 85 +/- 1.5mm long card; 0.2-1.2mm thick card(adjustable) ♦Error Card Reclaim: 25pcs at 8mm thickness cards |
|
Camera | ♦HD 1080p video quality at 30 frames-per-second ♦ H.264 with scalable video coding (SVC) and UVC 1.5 encoding technology ♦90-degree diagonal field of view ♦ Logitech RightLight™ 2 technology and autofocus ♦ 4X digital zoom in Full HD ♦ Pan, tilt and zoom option controlled by software ♦ ZEISS® glass lens ♦Convenient privacy shutter ♦ Plug-and-play USB connectivity ♦Multiple mounting options |
|
Passport scanner | ♦Image Acquisition: Collection area 127*88 mm; Sensor CMOS 5 million pixels (2592*1944); Resolution 500 DPI ♦Image save: 24-bit clear color photos can be taken of the full page information page of the passport, Images collected under visible light (white light), infrared light, and ultraviolet light sources can be saved in various image formats such as BMP, PNG or JPEG and the photos will not contain light spots caused by reflections;At the same time, you can also save the electronic avatar photo from the certificate with the chip; ♦Identification(OCR): Supports image collection and information recognition of various ID documents such as ID cards, driving licenses, passports, Hong Kong and Macau passes, Taiwan compatriots permits, and driving permits; Support image collection and information recognition of ICAO9303 standard passports, visas and other travel documents, including machine-readable codes and other layout information; Supports reading 1D barcodes, Code 128, Code 39, EAN-13, etc.Support reading 2D barcodes, PDF 417, QR, DataMatrix™, etc. Photo recognition speed is less than 1 second |
